Sokongan teknikal untuk pelanggan pada fungsi utama trak bomba, operasi dan penyelenggaraan, perkhidmatan selepas jualan yang paling profesional untuk trak Bomba.
ISUZU QL1070BUKWY foam tender fire service truck drawing, also called as Isuzu foam fire vehicle drawing or Isuzu rescue fire truck drawing, is composed of components such as the Isuzu QL1070BUKWY chassis, water and foam tanks, fire pump, piping system, and instrument & electrical system. The Isuzu chassis Foam Tank Fire Truck is equipped with a detachable aluminum alloy rear ladder, and the pump room is located at the rear of the truck. The tanks adopt a steel plate welded structure, with a water capacity of 1.36 cubic meters and a foam liquid capacity of 0.5 cubic meters. ▶Truck Model : ISUZU Foam tender fire service truck ▶Speficiation : 1500 L water + 500 L foam ▶Application Area : Fire resuce department / Municipal fire bureau Truck Item Speficiation Project Location ISUZU 4x2 Foam Fire Truck 1500 liters, 500 Liters Fire rescue department ISUZU QL1070BUKWY foam tender fire service truck drawing Item Specification Vehicle Model CS5070GXFPM20/Q6A Overall Dimensions 6800×1990×2990 mm Gross Vehicle Mass 6800 kg Liquid Capacity 1500 L (Water); 500 L (Foam) Max. Speed 95 km/h Rated Flow of Fire Pump 30 L/s @ 1.0 MPa Rated Flow of Fire Monitor 24 L/s @ 0.8 MPa Fire Monitor Range ≥55 m (Water); ≥42 m (Foam) Approach Angle / Departure Angle 24° / 14° New ISUZU 2000L water foam fire fighting trucks technical drawing share 2026 ISUZU Foam fire vehicle CAD drawing share 2026 ISUZU cab chassis fire truck drawing share Original technical drawing for Isuzu foam fire engine Isuzu chassis Foam Tank Fire Truck technical drawing The water tank of Isuzu foam fire truck is made of high-quality carbon steel plate with anti-corrosion treatment on the inner wall, while the foam tank is made of 304 stainless steel. The fire truck is fitted with a Model CB10/30 fire pump and a Model PL8/24 dual-purpose fire monitor. Item Specification Chassis Model Isuzu 600P QL1070BUKWY, China National Stage VI Emission Drive Type 4×2 Wheelbase 3815 mm Max. Speed 115 km/h Engine Model 4KH1CN6LB Rated Power 88 KW Gross Mass 7020 kg ISUZU Fire engine front view Foam tender Front right view Foam fire vehicle rear view Item Specification Capacity 1360 L (Water); 500 L (Foam) Material Water tank: high-quality carbon steel plate with internal anti-corrosion treatment. - Bottom plate: 4 mm carbon steel plate - Side plates & end plates: 3 mm carbon steel plate - Top plate: 3 mm carbon steel checkered plate Foam tank: high-quality stainless steel plate. - Bottom plate: 4 mm stainless steel plate - Side plates & end plates: 3 mm stainless steel plate - Top plate: 3 mm stainless steel checkered plate Structure Steel plate welded structure with internal anti-slosh baffles Equipments • 1 manhole cover with quick locking and opening device...
The CS5030TXFQC15 Dongfeng Nissan RIV fire pickup Vehicle is modified on the basis of the Dongfeng Nissan ZN1033UCM6A 4WD pickup truck. The complete vehicle mainly consists of a double-cab pickup chassis with high maneuverability, warning lights, interior pull-out equipment trays and other components. Dongfeng Nissan RIV fire pickup drawing share ▶Truck Model : Dongfeng Nissan Rescue Fire pickup ▶Speficiation : Quickly rescue ▶Application Area : Fire resuce department / Municipal fire bureau Truck Item Speficiation Project Location DONGFENG NISAN 4x4 Fire pickup Lighting and fire equipments Fire rescue department Core Purpose: 01: Used for the transportation of emergency rescue equipment and materials in sudden natural disasters, safety accidents, fires and other emergencies. 02: Military, public security special service, fire rescue support. Item Specification Overall Dimensions (mm) 5537 × 1850 × 1950 Curb Weight (kg) 2205 Gross Vehicle Weight (kg) 2580 Engine Power (kW) 122 Number of Occupants 2+3 Maximum Speed (km/h) 155 Approach Angle / Departure Angle (°) 33 / 25 Specific Power (kW/T) 47.29 Emission Standard GB18352.6-2016 China Ⅵ Emergency Repair 03: Inspection and emergency repair of pipelines for petroleum, chemical industry, natural gas, water supply and power supply. 04: Transportation of equipment and materials for emergency repair and maintenance of equipment faults such as high-voltage power transmission and transformation lines, expressways and mines. Nissan fire pickup front view Side view fire pickup Rear view fire pickup Documents on board Item 01 Vehicle Technical Documents 02 Chassis Operation Manual 03 Chassis Number Rubbing 04 Chassis Maintenance Manual 05 Fire Truck Operation Manual 06 Chassis Quality Warranty Card 07 Fire Truck Certificate of Conformity 08 Chassis Certificate of Conformity 09 Fire Truck After-Sales Tracking Service Card 10 A Set of Chassis Tools 11 Fire Truck Handover List 12 Engine Number Rubbing Dongfeng Nissan Rescue Fire Pickup Factory Pictuers Main features of Dongfeng Nissan fire pickup:(1) High maneuverability and strong passability;(2) Equipped with pull-out equipment trays inside the vehicle for convenient and quick access.
FOTON 4x4 1500L Fire Pickup Rapid intervention vehicle, also named FOTON rescue pickup or Foton rapid fire engine, are widely used in various emergency rescue scenarios due to their high mobility, strong off-road capability, and flexible modification, and are especially suitable for complex terrains and narrow areas that are difficult for traditional large fire trucks to reach. The foton fire pickup is equipped with an aluminum alloy rear ladder (removable), with the pump room located at the rear of the vehicle.The tank is steel plate welded and made of high-quality aluminum alloy plate, with a water capacity of 1.5 cubic meters.The vehicle is equipped with a CB10/30 fire pump and a PS8/30W fire water monitor. FOTON 1500L Fire Pickup Rapid intervention vehicle technical drawing ▶Truck Model : FOTON 4x4 RIV rescue pickup ▶Speficiation : 1500 L water ▶Application Area : Fire resuce department / Municipal fire bureau Truck Item Speficiation Project Location FOTON 4x4 RIV pickup 1500 liters, 190 Hp engine Fire rescue department FOTON Rescue fire pickup CAD drawing FOTON Rescue fire pickup CAD drawing Foton RIV side view Foton fire pickup side view Foton fire engine rear view Item Specification Vehicle Model CS5040GXFSG15/B6B Overall Dimensions 5080 × 1940 × 2640 mm Maximum Total Mass 4130 kg Liquid Capacity 150 L (Water) Maximum Speed 135 km/h Rated Flow of Fire Pump 30 L/s @ 1.0 MPa Rated Flow of Fire Monitor 30 L/s @ 0.8 MPa Range of Fire Monitor ≥ 60 m (Water) Approach Angle / Departure Angle 28° / 23° FOTON RIV equipped fire pickup factory picture FOTON RIV equipped fire pickup factory picture FOTON RIV equipped fire pickup factory picture FOTON Fire pickup on board equipment: Category No. Name Specification Qty Unit Remarks Fire Extinguishing Equipment 1 Suction Hose DN100 8 m Threaded type 2 Strainer FLF100 1 pc Threaded type 3 Water Divider FII80/65×2-1.6 1 pc Instantaneous coupling 4 Water Manifold JII100/65×2-1.6 1 pc Internal thread to instantaneous coupling 5 Fire Hose 13-65-20 6 roll Normal pressure; instantaneous coupling 6 Fire Hose 13-80-20 2 roll Normal pressure; instantaneous coupling 7 Fire Hose 13-65-5 1 roll Instantaneous coupling (for external water filling) 8 Reducing Adapter KJ65/80 1 pc Instantaneous coupling 9 Hose Cloth - 4 pcs - 10 Hose Bridge - 2 pair - 11 Hose Hook - 4 pcs - 12 Above-ground Fire Hydrant Wrench - 1 pc - 13 Underground Fire Hydrant Wrench - 1 pc - 14 Suction Hose Wrench 100 2 pcs - 15 Straight Stream Shut-off Nozzle QZG3.5/7.5; 65 1 pc Instantaneous coupling 16 Straight Stream & Spray Nozzle QLD6.0/6.5I; 65 1 pc Instantaneous coupling Forcible Entry & Rescue Tools 1 Fire Extinguisher 3kg / ABC 1 unit - ...
CS trucks as the most professional Water foam powder firefighting vehicle manufacturer in China, all our Dry powder and foam combined fire trucks are particularly suitable for extinguishing fires involving flammable gases, flammable liquids, organic solvents, electrical equipment, and general materials. They are widely used in high-risk locations such as petrochemical enterprises, oil depots, airports, ports, and urban special service fire stations. This Isuzu Water foam powder firefighting vehicle technical drawing is primarily designed for light and small fire fighting trucks. For example, city narrow road, small oil gas station,chemial area, highway department. Upon on different kinds of commands, customer can require wide range of wheelbase ( 3900 mm, 4500mm, 5000mm) and engine horse power ( 240 Hp, 300 Hp) ▶Truck Model : Isuzu FVR/GIGA ▶Speficiation : 3000 L water + 1000 L foam + 1000L dry powder ▶Application Area : Fire resuce department / Municipal fire bureau Truck Item Speficiation Project Location Isuzu 4x2 foam powder fire truck 5000 liters, 240 Hp engine Fire rescue department 2026 NEW Water foam powder firefighting vehicle drawing share 2026 NEW Water foam powder firefighting vehicle drawing share 2026 dry powder firefighting vehicle dry powder testing 2026 NEW Water foam powder firefighting vehicle water jetting testing Design Section Specific design content 1. Design Overview 1. Applicable scenarios: High-risk locations such as petrochemical enterprises, large oil depots, and airports. 2. Functional Features: Integrates dry powder and foam fire extinguishing technologies, suitable for extinguishing fires involving flammable liquids, combustible gases, electrical equipment, and general fires; prevents reignition and provides rapid fire control. 3. Design Standards: Complies with national standards such as GB 7956.4-2019 and GB 7956.2-2014. 2. Vehicle Chassis Design 1. Powertrain Configuration: 6×4 internationally renowned brand chassis, V6 turbocharged diesel engine, power ≥350KW, China VI emission standard, power-to-weight ratio ≥10Kw/t, speed ≥100km/h 2. Basic configuration: ABS+ASR intelligent braking, full- power PTO , front and rear tow hooks, and metal parts resistant to seawater corrosion. 3. Cabin: Flat-front, four-door, double-row seating, accommodating 6 people; equipped with a panoramic recorder, reversing camera, and in-car radio; adjustable seats with air respirator brackets for safety and convenience. 3.1. Upper Structure System Design – Tank System 1. Volumetric structure: Internal compartmentalized design, total volume ≥12m³ (water tank ≥6m³, foam tank ≥3m³, dry powder tank ≥3m³) 2. Material and manufacturing process: 304 stainless steel, bottom plate ≥5mm, side plate ≥4mm; internal anti-sloshing baffle, m...
Beiben Fire Truck based on type II Beiben 2638 model 6*4 Left Hand Drive chassis, body capacity could up to 12,000Liters, including 10,000Liters water tanker and 2,000Liters foam tank, Beiben 2638 fire rescue truck equipped with XIONGZHEN CB10/60 fire pump and PL8/48 fire monitor, very convenient for daily use. Mainly used for firefighting project in any areas of need. The vehicle designed to fully rely on the advantages of the original of Beiben brand truck chassis, fully consider the product's convenience and reliability, also the newly designed chassis. The body material is international standard carbon steel with anti-corrosion painting and stainless steel, which can effective to avoid rusting and service for long life. The Beiben 6x4 Fire Truck equipped with Sandwich PTO, fire pump, fire monitor, crew room, hose box, pump room, dry powder tanker and nitrogen system, matched with pipeline hose reel, English version control box, inlet and outlet pipeline, rear climbing ladder, top pillow lamp, and all necessary firefighting equipment. Customized Double-row cabin with 2+4 seats nice driving feeling. Therefore, the vehicle is an ideal Fire Truck mainly for firefighting project.
Isuzu 700P foam fire fighting is emergency quick action fire rescue trucks. It has great advantage on japan isuzu 4x2 and 4x4 drive truck chassis, in terms of dacades of experience on this classic rigid truck chassis, Isuzu 700P water foam truck has become the first choice of many fire departments. This Isuzu ELF fire rescue truck technical drawing is primarily designed for light and small fire fighting trucks. For example, city narrow road, small oil gas station,chemial area, highway department. Upon on different kinds of commands, customer can require wide range of wheelbase ( 3360 mm 3815 mm, 4715 mm) and engine horse power ( 190 Hp, 205 Hp) ▶Truck Model : Isuzu 700P/ELF ▶Speficiation : 2000 L water + 500 L foam ▶Application Area : Fire resuce department / Municipal fire bureau Truck Item Speficiation Project Location Isuzu 4x2 foam fire truck 2500 liters, 190 Hp engine Fire rescue department 3 options for Isuzu ELF 700P fire rescue trucks
Yang Trak bomba penyelamat kecemasan HOWO dengan kren ialah trak bomba pelbagai fungsi yang mengintegrasikan keupayaan perobohan, penundaan, pengangkatan dan pencahayaan, yang direka khusus untuk tempat kejadian bencana yang kompleks. Konfigurasi terasnya termasuk kren boom lipat 5 tan, win hidraulik 3 tan, lampu sorot 500W dan set penjana, yang membolehkannya melakukan tugas mengangkat, menunda dan pencahayaan. Ia sesuai untuk bencana alam dan kemalangan jalan raya, melakukan tugas perobohan, menyelamat dan penjanaan kuasa. Reka bentuk modularnya membolehkan pelarasan pantas pada susun atur peralatan untuk disesuaikan dengan keperluan menyelamat yang berbeza. ⇒ Muat Turun PDF Lukisan : Lukisan teknikal kren yang dipasang pada trak pemadam kebakaran HOWO Lukisan teknikal kren yang dipasang pada trak pemadam kebakaran HOWO pandangan kiri hadapan Kenderaan Pemadam Kebakaran Kren Penyelamat Kecemasan HOWO Spesifikasi utama Kabin KABIN BERDUAL, 6 ORANG DIBENARKAN Kren Model SQ5ZK2 Kapasiti mengangkat 5000kg Kuantiti lengan 3 Winch Kuantiti 1 Kapasiti 3000kg Lampu carian Sudut berputar 360 ° Ketinggian kerja 5m, pengangkatan automatik Buble 500w*4 keping Halaju angin maksimum
Pelanggan Afrika Mauritania membeli 4 unit sepenuhnya Sinotruk HOWO mesin bomba pam dari POWERSTAR TRUCKS dan digunakan di ibu negara Nouakchott. Trak bomba juga boleh dipanggil enjin bomba dan pam bomba, iaitu kenderaan yang direka dan dikeluarkan untuk memenuhi keperluan pelbagai projek pemadaman kebakaran dan menyelamat orang di peringkat antarabangsa. Barisan kabin berganda tersuai untuk pengangkutan anggota bomba, pelbagai peralatan dan alatan pemadaman kebakaran untuk pemadaman kebakaran, penyelamatan kebakaran, dan sebagainya. Bagi menjamin trak pemadaman kebakaran HOWO berfungsi dengan lebih cekap, kami telah menyesuaikan diri untuk mempunyai trak yang dilengkapi dengan tangga aloi Aluminium, busa air dan agen kebakaran serbuk kering dan tangki simpanan, pam bomba model CB10/60 yang cekap dipadankan dengan monitor kebakaran PL8/48, dan jarak pancutan yang cekap melebihi 70m, gelendong hos pemadaman kebakaran dengan pistol untuk pemadaman kebakaran jarak jauh, alat pernafasan dengan topeng, pakaian pelindung, alat menyelamat, kit pertolongan cemas, dan sebagainya. Semua perkhidmatan untuk trak bomba HOWO untuk kerja yang cekap dan boleh dipercayai. Bagi menjamin pelanggan Mauritania menggunakan enjin bomba HOWO dengan lebih mudah dan cekap, semua trak dipadankan dengan set lengkap katalog versi Inggeris untuk perkhidmatan, termasuk Manual Pengguna untuk panduan operasi, Manual Trak dan Manual Alat Ganti untuk penggunaan dan penyelenggaraan. Trak Bomba Pam Serbuk SINOTRUK HOWO 14,000L Kilang POWERSTAR adalah pengilang profesional dalam bidang trak, menjamin semua produk Baharu dan Berkualiti Tinggi. » Ⅰ. Kelebihan Trak Bomba HOWO: ★ Enjin diesel WEICHAI berkuasa 247KW / 336HP, 100,000 Km tanpa masalah. ★ Kabin HW76 klasik SINOTRUK HOWO, reka bentuk Eropah ★ Pam bomba CB10/60 yang dipasang, kadar aliran 60L/s, sangat andal ★ Meriam tembakan air PL8/48 yang dipasang di bahagian atas, perkhidmatan yang tahan lama ★ Serbuk kering 500L dengan botol Nitrogen, dengan injap kawalan udara ★ Sistem kawalan bersepadu untuk busa dan serbuk, dengan panel di bahagian belakang » Ⅱ . Lukisan Jentera Bomba Penyelamat Howo: [jika gte mso 9]> Normal 0 7.8 Jarak 0 2 false false false EN-US ZH-CN AR-SA Locked="false" SemiHidden="true" UnhideWhenUsed="true" Name="Indent First Text Body"/> (NamaWebSebenar) Locked="false" SemiHidden="true" UnhideWhenUsed="true" Name="HTML Acronym"/> WhenUsed="true" Table Grid 4" SemiHidden="true" UnhideWhenUsed="true" Name="Table Grid 5"/> WhenUsed="true" Name="Table Grid 6"/> To guarantee Mauritania Nouakchott clients purchased satisfy HOWO 6x4 Water & Foam & Powder Fire Truck, so we POWERSTAR Engineer Department do design the truck firstly, then start for production. Howo fire truck equipped with Sandwich PTO, fire pump, fire monitor, crew room, hose box, pump room, English version control box, inlet and outlet pipeline, rear climbing ladder, top pillow lamp, all necessary firefighting equipment, and dry powder system. Customize...
680+Projek Selesai
+86 188 0866 8888
Sebagai seorang xiongzhen profesional pengeluar pam kebakaran di China, Trak Powerstar memiliki siri produk jenama sendiri "Xiongzhen", termasuk pam bomba tekanan rendah, pam bomba tekanan sederhana rendah, dan pam bomba tekanan tinggi rendah yang dipasang pada kenderaan, serta peralatan sokongan seperti pemantau kebakaran dan pengatur busa. Pam bombanya menggunakan bahan baharu seperti aloi alumi...
Baca lebih lanjutPF5-15 monitor serbuk kering tetap Menggunakan serbuk kering sebagai medium dan bergantung pada tapak tetap untuk semburan yang stabil. Ia sesuai untuk kawasan kimia dan gudang, dan boleh menutup permukaan yang terbakar dengan cepat pada peringkat awal kebakaran, meningkatkan kecekapan pemadaman. Yang Monitor serbuk kering tetap PF5-15 mempunyai struktur yang teguh, mudah dikendalikan, dan boleh d...
Baca lebih lanjutPam pemadam kebakaran buih CB10/140 ialah sistem bekalan air kebakaran yang dipasang pada kenderaan atau pegun yang biasa digunakan dengan tekanan undian 1.0 MPa dan kadar aliran undian 140 L/s, memenuhi keperluan bekalan air teras sistem pemadam kebakaran. Badan pam dan pendesak dibina daripada bahan berkualiti tinggi dan tahan haus, menawarkan rintangan kakisan dan rintangan tekanan tinggi. Ia m...
Baca lebih lanjutTrak bomba Isuzu 6HK1-TC , juga dinamakan Kenderaan bomba penyelamat Isuzu , Diagnosis dan Penyelesaian Kod Ralat Enjin. Enjin Isuzu 6HK1-TC menggunakan sistem kawalan elektronik pam suntikan bahan api TICS yang canggih, dan ECU (Unit Kawalan Enjin) mempunyai ciri diagnosis kendiri. Apabila sistem mengesan kerosakan, lampu amaran "CEK ENJIN" akan menyala dan kod kerosakan yang sepadan akan disimpa...
